- Power Supply Magnetic MLV 200W 12V with any LV magnetic dimmer as long as you cover dimmer’s min load.
- Temperature class B(130°C).
- Two section bobbin completely separated primary and secondary windings.
- Input leads are 18AWG 600V.
- Output leads are 12AWG 300V.
- Leads max. operational temperature is 105°C.
- Thermal manually reset primary breaker 3A.
- Thermal manually reset secondary breaker 13A
- The actual Power Supply Magnetic MLV 200W 12V transformer 200W is encapsulated in the enclosure.
- The enclosure is Black Powder Coated Steel, NEMA 3R rated.
- Wiring compartment has 3 knockouts sizes for 3/8 inch screw cable connectors.
- Enclosure Temperature does not exceed 75°C at 45°C ambient and fully loaded.
- Dimensions (inch): H = 8, W = 4.1, D = 3.24.
- Weight (LBs): 9.
- Input Voltage: 120V 60Hz.
- Max. input current at full load: 2A.
- Output voltage without load: 13.6VDC.
- Output voltage fully loaded: 11.5VDC.
- Max. Total Wattage: 200W.
- Max. Output Current: 16.6A.
- Efficiency: 93%
